Hybrid Dual Shaft Nema 23 Bipolar 23HS45-3008D (2.5Nm/3A)

SKU
MD-00994
PKR12,300.00
Quantity: 0
Hybrid Dual Shaft Nema 23 Bipolar 23HS45-3008D (2.5Nm/3A)
  • Buy 3 for PKR11,685.00 each and save 5%
  • Buy 10 for PKR11,316.00 each and save 8%

SPECIFICATIONS:

  • Motor Type: Unipolar/Bipolar Stepper
  • Step Angle: 1.8 deg
  • Holding Torque(Unipolar): 1.7Nm(240.7oz.in)
  • Holding Torque(Bipolar Serial): 2.5Nm(354oz.in)
  • Holding Torque(Bipolar Parallel): 2.5Nm(354oz.in)
  • Rated Current/phase(Unipolar): 3.0A
  • Rated Current/phase(Bipolar Serial): 2.12A
  • Rated Current/phase(Bipolar Parallel): 4.24A
  • Phase Resistance(Unipolar): 0.8 ohms
  • Phase Resistance(Bipolar Serial): 1.6 ohms
  • Phase Resistance(Bipolar Parallel): 0.4 ohms
  • Inductance(Unipolar): 1.7mH ± 20%(1KHz)
  • Inductance(Bipolar Serial): 6.8mH ± 20%(1KHz)
  • Inductance(Bipolar Parallel): 1.7mH ± 20%(1KHz)

RELATED DOCUMENTS:

DIMENSIONS:

  • Frame Size: 57 x 57mm
  • Body Length: 114mm
  • Front Shaft Diameter: Φ8mm
  • Rear Shaft Diameter: Φ6.35mm
  • Front Shaft Length: 21mm
  • D-cut length: 15mm
  • Rear Shaft Length: 15mm
  • Number of Leads: 8
  • Lead Length: 500mm

PACKAGE INCLUDES:

  • 1 X Hybrid Dual Shaft Nema 23 Bipolar 23HS45-3008D (2.5Nm/3A)
Part Number 23HS45-3008D
Weight (KG) 2.000000
Manufacturer stepperonline
Product Availability Available on Demand
Model Number 23HS45-3008D
Voltage (Min) NA
Voltage (Max) NA
Current (A) 3
Temperature Range (Min) 0°C
Temperature Range (Max) 70°C
Step Per Revolution(Min) NA
Step Per Revolution (Max) NA
Torque 2.5Nm(354oz.in)
Motor Type Unipolar/Bipolar Stepper
Motor Step Angle 1.8°
