Nema 8 Bipolar Stepper Motor 8HS15-0604S (0.6A /4Ncm)
SKU
MD-00744
PKR4,650.00
Quantity: 0
Nema 8 Bipolar Stepper Motor 8HS15-0604S (0.6A /4Ncm)
- Buy 5 for PKR4,420.00 each and save 5%
- Buy 20 for PKR4,185.00 each and save 10%
Categories: Electronics Parts, Robotics, Motors, Stepper Motors
This is the highest torque for Nema 8 stepper motor with 1.8° step angle (200 steps/revolution). Each phase draws 600mA, allowing for a holding torque of 4Ncm(5.7oz.in).
SPECIFICATIONS:
|
Manufacturer Part Number |
8HS15-0604S |
|
Motor Type |
Bipolar Stepper |
|
Step Angle |
1.8° |
|
Holding Torque |
4Ncm(5.7oz.in) |
|
Rated Current/phase |
0.6A |
|
Phase Resistance |
10ohms |
|
Recommended Voltage |
12-24V |
|
Inductance |
5.5mH±20%(1KHz) |
RELATED DOCUMENTS:
PIN CONFIGURATIONS:
|
Wire Color |
Black |
Green |
Red |
Blue |
|
Board Connector |
A |
C |
B |
D |
PACKAGE INCLUDES:
- 1 X Nema 8 Bipolar Stepper Motor 8HS15-0604S (0.6A /4Ncm)
| Part Number | NA |
|---|---|
| Weight (KG) | 0.080000 |
| Manufacturer | Made in China |
| Model Number | 8HS15-0604S |
| Voltage (Min) | 12v |
| Voltage (Max) | 24V |
| Current (A) | 0.6 |
| Temperature Range (Min) | -40°C |
| Step Per Revolution(Min) | NA |
| Step Per Revolution (Max) | 200 |
| Torque | 4Ncm |
| Size (mm) | NA |
| Motor Type | Bipolar Stepper |
| Motor Step Angle | 1.8° |
