AutomationDirect: CLICK Basic PLC, 24 VDC, Serial Ports, Discrete Input: 8-Point, Discrete Output: 6-Point - C0-00DD2-D

Quantity: 0
CLICK Basic PLC, 24 VDC required, serial ports, Discrete Input: 8-point, DC, Discrete Output: 6-point, sourcing.

C0-00DD2-D Specifications

PDF  Technical Specifications

Technical Attributes
Item PLC
Series Basic
Ladder Memory 8k steps
User Data Memory 16 KB
Programming Language Ladder
Programming Software CLICK programming software v1.00 or later and CLICK CPU firmware v1.00 or later
Communication Port and Connection Type(s)
  • (2) RS-232 (RJ12)
Port Protocol(s)
  • Modbus RTU Master/Slave
  • ASCII In/out
  • programming and monitoring
Port Speed(s)
  • up to 115.2k baud
Real Time Clock/Calendar No
Retentive Memory No
Battery Backup No
Maximum Expansion Modules Allowed 8
External Power Requirement 24 VDC
Number of Discrete Input Points 8
Nominal Input Voltage 24 VDC
Voltage Type DC
Discrete Input Type Sinking/sourcing
Number of Isolated Discrete Input Commons 2
Number of Points per Discrete Input Common 4
Number of Discrete Output Points 6
Nominal Output Voltage 24 VDC
Discrete Output Type Sourcing
Load Current 0.1A/point
Number of Isolated Discrete Output Commons 1
Number of Points per Discrete Output Common 6
Includes Removable terminal block

C0-00DD2-D What's in the Box

PLC unitInfo
20 postion terminal block~attached to PLC unitInfo
4 postion terminal block~attached to PLC unitInfo
Extention port cover~attached to PLC unit
Part Number C0-00DD2-D
Manufacturer Automation Direct
Weight (KG) 0.050000
Product Availability Available on Demand
