Meanwell: AC-DC Industrial DIN Rail Power Supply; Output 24Vdc at 4A; - MDR-100-24
SKU
MD-01711
PKR11,200.00
Quantity: 1
- Buy 3 for PKR10,640.00 each and save 5%
- Buy 10 for PKR10,304.00 each and save 8%
Category: Power Supply
MEAN WELL MDR AC/DC Din Rail power supplies are 10W to 96W Ultra Slim power supplies in a plastic case. Mean Well MDR AC/DC Din Rail power supplies feature a universal AC input / full range and short circuit, overload, and overvoltage protection. MDR features no load power consumption <0.75W to 1W.
Features
- Plastic case, ultra slim
- Universal AC input / full range
- No load power consumption<0.75W to 1W
- Assemble on industrial rail TS-35 / 7.5 or 15
- Built-in active PFC function
- DC OK signal output (MDR-10/20)
- DC OK relay contact (MDR-40/60/100)
- Class I, Div 2 Hazardous Locations T4 (MDR-40/60)
Specifications
| Technical data | Information | ||
|---|---|---|---|
|
Brand
|
Mean Well
|
Commodity
|
8504409090
|
|
Item number
|
MDR-100-24
|
Warranty pack
|
36 Months Bring-In
|
|
Series
|
MDR-100
|
RoHS
|
Compliant
|
|
Description
|
AC-DC Industrial DIN rail power supply; Output 24Vdc at 4A; plastic case
|
Packing quantity
|
30
|
|
Application
|
Installation UL 508
ITE EN/UL/IEC 60950
|
Net weight (gram)
|
456
|
|
Technology
|
AC/DC
|
||
|
Power Format
|
DIN rail
|
||
|
Output Power (W)
|
96
|
||
|
Output Voltage (V)
|
24
|
||
|
Output Current (A)
|
4
|
||
|
Input Voltage (V)
|
90 - 264
Universal Input 110/230V
|
||
|
IP Rating
|
No IP assigned
|
||
|
Width (mm)
|
55
|
||
|
Height (mm)
|
90
|
||
|
Depth (mm)
|
100
|
||
|
Control Signals
|
DC OK
|
||
|
Dimming Technology
|
No Dimming
|
||
| Part Number | MDR-100-24 |
|---|---|
| Manufacturer | Mean Well |
| Weight (KG) | 0.400000 |
| Product Availability | In Stock |
