Phoenix Contact Relay Module PLC-RSC- 24DC/21 2966171

SKU
PC-00017
PKR2,350.00
Quantity: 0
Phoenix Contact Relay Module PLC-RSC- 24DC/21 (2966171) consisting of base terminal block 2966016 with screw connection and pluggable miniature relay with power contact, for assembly on DIN rail NS 35/7.5, 1 PDT, input voltage 24 V DC
  • Buy 10 for PKR2,279.50 each and save 3%
  • Buy 50 for PKR2,232.50 each and save 5%
  • Buy 250 for PKR2,209.00 each and save 6%

This relay module consists of following two items:

FEATURES:

  1. Test voltage relay winding/relay contact: 4 kV AC (50 Hz, 1 min.)
  2. Operating mode: 100% operating factor
  3. Mechanical service life: 2 x 107 cycles
  4. Flammability rating according to UL 94: V0
  5. Designation: Standards/regulations
  6. Pollution degree: 3
  7. Overvoltage category: III
  8. Mounting position: any
  9. Assembly instructions: In rows with zero spacing

SPECIFICATION:

  1. Connection method: Screw connection
  2. Stripping length: 8 mm
  3. Screw thread: M3
  4. Conductor cross section solid: 0.14 mm² ... 2.5 mm²
  5. Conductor cross section flexible: 0.14 mm² ... 2.5 mm²
  6. AWG conductor cross section: 26 ... 14
  7. Nominal input voltage UN: 24 V DC
  8. Typical input current at UN: 9 mA
  9. Typical response time: 5 ms
  10. Typical release time: 8 ms
  11. Operating voltage display:      Yes
  12. Power dissipation for nominal condition: 0.22 W

PARAMETERS:

  1. Width: 6.2 mm
  2. Height: 80 mm
  3. Depth: 94 mm

PACKAGE INCLUDES:

  1. 1 X Phoenix Contact Relay Module PLC-RSC- 24DC/21 (2966171)
Part Number 2966171
Manufacturer phoenix contact
Weight (KG) 0.031060
Product Availability In Stock
Packing Unit 10 Pieces
Custom tariff number 85364190
GTIN 4017918130732
