Sparkfun - XBee Explorer Regulated Board

SKU
MD-00549
PKR1,980.00
Quantity: 0
The SparkFun XBee Explorer Regulated takes care of the 3.3V regulation, signal conditioning, and basic activity indicators (Power, RSSI and DIN/DOUT activity LEDs).
  • Buy 3 for PKR1,885.00 each and save 5%
  • Buy 10 for PKR1,780.00 each and save 10%

The SparkFun XBee Explorer Regulated takes care of the 3.3V regulation, signal conditioning, and basic activity indicators (Power, RSSI and DIN/DOUT activity LEDs). It translates the 5V serial signals to 3.3V so that you can connect a 5V (down to 3.3V) system to any XBee module. The board was conveniently designed to mate directly with the SparkFun Arduino Pro series of boards for wireless bootloading and USB based configuration.

 This unit works with all XBee modules including the Series 1 and 2, standard and Pro versions. Plug an XBee into this breakout and you will have direct access to the serial and programming pins on the XBee unit and will be able to power the XBee with 5V. This board comes fully populated with 3.3V regulator (5V max input), XBee socket, four status LEDs, and level shifting. In the latest revision the diode level shifter is replaced with a more robust MOSFET level shifter. This board does not include and XBee module.

RELATED DOCUMENTS:

  1. Schmatic Diagram.
  2. User Guide.

PACKAGE INCLUDES:

  1. 1 X XBee Explorer Regulated Board
Part Number NA
Weight (KG) 0.020000
Manufacturer Sparkfun
Voltage (Min) NA
Voltage (Max) 5V
Output Voltage 3.3V
Power NA
Frequency NA
Load Cell (kg) NA
Output Type NA
Range NA
Temperature Range (Min) -40°C
Operating System NA
Resistance Value (Ohm) NA
Baud Rate NA
Interface NA
Num of Pin's NA
Diameter NA
Size (mm) NA
