Texas Instruments - Hercules RM57Lx LaunchPad Development Kit LAUNCHXL2-RM57L

SKU

MD-01105

Skip to the beginning of the images gallery

PKR24,500.00

Quantity: 0

The Hercules™ RM57Lx Launchpad™ Development Kit is based on the highest performance Hercules MCU RM57L843 – lockstep cached 330MHz ARM® Cortex®-R5F based RM series MCU. Hercules MCUs are designed to aid in the development of IEC 61508 functional safety industrial and medical applications.

Buy 3 for PKR23,275.00 each and save 5%
Buy 10 for PKR22,540.00 each and save 8%

Notify me when the price drops

Category: Development Boards

Details

Description

The LaunchPad features connectivity options such as IEEE 1588 precision time Ethernet PHY DP83630 and has the capability in addition to the standard BoosterPack headers, for further expansion to an FPGA or an external SRAM using high density connectors for MCU’s parallel interfaces - EMIF, RTP and DMM.

The RM57Lx MCUs include many diagnostic features such ECC protection for CPU caches & other memories and a rich set of peripherals such as two 12-bit ADCs, programmable High-End timers, motor control peripherals (eQEP, eCAP, ePWM), Ethernet, MibSPI, EMIF and many serial communication interfaces.

This LaunchPad is pre-programmed with a Hercules safety MCU demo enabling users to easily learn about the key safety, data acquisition and control features of the Hercules MCU platform.

Find additional information on LaunchPad Development Kits, supported BoosterPacks and available resources at ti.com/launchpad. Visit the LAUNCHXL2-RM57L Wiki for software downloads including Ethernet connectivity using lwIP and other resources. Explore different applications on your LaunchPad Development Kit with BoosterPack plug-in modules.

Features

USB powered and capability for external 5v supply
On board USB XDS_ICDIc2 JTAG debug
IEEE 1588 precision time Ethernet PHY DP83630
On board SCI to PC serial communication
User programmable push buttons
Reset switches
LEDs and Analog input
Two 40 pin BoosterPack XL Headers (one populated)
High density connectors for parallel ports (EMIF, RTP, DMM) for further expansion
Footprint for prototyping headers (not populated) to bring out all MCU Pins
External high-speed emulation via 14-pin TI-JTAG header (not populated)
