STMicroelectronics - Darlington NPN Power Transistor TIP142
SKU
MD-01157
PKR330.00
Quantity: 0
The devices are manufactured in planar technology with “base island” layout and monolithic Darlington configuration. The resulting transistors show exceptional high gain performance coupled with very low saturation voltage
- Buy 10 for PKR295.00 each and save 11%
- Buy 100 for PKR245.00 each and save 26%
- Buy 500 for PKR210.00 each and save 36%
- Buy 1000 for PKR195.00 each and save 41%
- Buy 2500 for PKR178.00 each and save 46%
Category: Transisters
The devices are manufactured in planar technology with “base island” layout and monolithic Darlington configuration. The resulting transistors show exceptional high gain performance coupled with very low saturation voltage.
Key Features
- Monolithic Darlington configuration
- Integrated antiparallel collector-emitter diode
| Categories | Discrete Semiconductor Products | |
|---|---|---|
| Transistors - Bipolar (BJT) - Single | ||
| Manufacturer | STMicroelectronics | |
| Series | - | |
Packaging  |
Tube |
|
| Part Status | Active | |
| Transistor Type | NPN - Darlington | |
| Current - Collector (Ic) (Max) | 10A | |
| Voltage - Collector Emitter Breakdown (Max) | 100V | |
| Vce Saturation (Max) @ Ib, Ic | 3V @ 40mA, 10A | |
| Current - Collector Cutoff (Max) | 2mA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 1000 @ 5A, 4V | |
| Power - Max | 125W | |
| Frequency - Transition | - | |
| Operating Temperature | 150°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | TO-247-3 | |
| Supplier Device Package | TO-247 | |
| Base Part Number | TIP142 |
| Part Number | TIP142 |
|---|---|
| Weight (KG) | 0.007000 |
| Manufacturer | STMICROELECTRONICS |
| Voltage (V) | NA |
| Output Voltage | NA |
| Transistor Polarity | NPN |
