Microchip: PIC16F1459-I/SO, 8-bit 48MHz Microcontroller 20Pin - SOIC-20
SKU
MD-02321
PKR 950.00
High-performance, low-power Microchip PIC16F1459-I/SO 8-bit microcontroller featuring full-speed USB 2.0 support without the need for an external crystal. Packaged in a compact 20-pin SOIC layout, it is highly optimized for embedded connectivity, USB dongles, and industrial control interfaces.
⚡ Real-Time Stock:
10 Units
✔ In Stock & Ready to Ship
- Buy 3 for PKR 902.50 each and save 5%
- Buy 10 for PKR 874.00 each and save 8%
Category: Micorocontroller
The PIC16F1459-I/SO belongs to Microchip's enhanced mid-range 8-bit core family, delivering advanced peripherals at a highly competitive cost. This chip stands out for its universal serial bus (USB) capabilities, utilizing an internal clock tuning mechanism (Active Clock Tuning) to eliminate expensive external crystals. Armed with 14 KB of flash memory, an integrated 10-bit ADC, and versatile communication modules (I2C, SPI, EUSART), it serves as a highly robust control unit for consumer electronics, industrial automation, and medical devices.
Technical Specifications:
| Attribute Code | Attribute Label | Value |
|---|---|---|
| manufacturer | Manufacturer | Microchip Technology |
| mfg_part_number | Manufacturer Part Number | PIC16F1459-I/SO |
| core_architecture | Core Architecture | PIC |
| core_size | Core Size | 8-Bit |
| speed | Maximum Speed | 48 MHz |
| program_memory_size | Program Memory Size | 14 KB (8K x 14) |
| program_memory_type | Program Memory Type | Flash |
| ram_size | RAM Size | 1024 Bytes (1 KB) |
| connectivity | Connectivity | I2C, SPI, UART/USART, USB 2.0 |
| peripherals | Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| number_of_io | Number of I/O Pins | 17 |
| adc_channels | ADC Channels | 9 Channels (10-bit resolution) |
| operating_voltage | Supply Voltage (Vcc/Vdd) | 2.3V to 5.5V |
| operating_temperature | Operating Temperature | -40°C to +85°C (Industrial Class) |
| package_case | Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| mounting_type | Mounting Type | Surface Mount (SMD/SMT) |
| Part Number | PIC16F1459-I/SO |
|---|---|
| Manufacturer | Microchip |
| Weight (KG) | 0.001000 |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
