Xi'an: Micro D-Sub 37-Pin Female Socket Connector - J30J-37ZKNP5-J

SKU
MD-01728
PKR7,850.00
Quantity: 10
J30J 37pins with Micro D-sub Miniaturized Rectangular Connector
  • Buy 3 for PKR7,457.50 each and save 5%
  • Buy 10 for PKR7,222.00 each and save 8%

J30J connector' shell is aluminum alloy, contact space is 1.27mm, apply to the wire core section area is 0.1-0.15mm squared. It meets the requirements of MIL-DTL-83513. With the small install space, light weight , reliable connect, excellent electromagnetic scree, good earthquake resistance, etc. it is widely used in small space required electronic equipment and apparatus.

 Features:

² 0.635mm,1.27mm,1.91mm contact spacing

² 1, 2, 3 ,4-raw options

² 9-100contacts

² MIL-DTL-83513 qualification

² Straight, right-angle models choice

² Space and weight saving.

² Excellent resistance to shock and vibration.

² Low contact resistance, high current capability, high dielectric strength.

² Custom designed connectors and cable assemblies.



Applications:

² Avionics, radars

² Missiles and guidance systems

² On-board equipment

² Telecommunication systems

² Navigation systems

² Research centres

² Medical applications

² Cable to Cable

² Board to Cable

² Surface Mount (SMT) Board to Cable



Specification:

Technical Characteristics

Rated Current

3A

Insulation Resistance

≥ 5000 MΩ

Dielectrics Voltage-resistance

800V

Mechanical life

500 cycles

Environmental Conditions

Environmental Temperature

-55℃ ~ + 125℃

Vibration

10Hz~ 2000Hz  196m/s²



Random Vibration

Power Spectral Density (PSD) 0.4G2/Hz

Total Acceleration RMS Value 23.1G

Shock

Acceleration 735m/s²  11m/s2





Part Number J30J-37ZKNP5-J
Packing Unit 1 Piece
Product Availability Available on Demand
