Weinview: HMI 7" Touch Screen Display with Ethernet - TK8072iP
SKU
MD-02131
PKR 39,500.00
🔥 High Demand Allocation:
1 Units
⚠️ Limited Quantity Remaining
Categories: LCDs, Display Screens LCDs, Human Machine Interface HMI
Features
- 7' 800x480 TFT LCD, LED backlight
- Fanless cooling system
- Built-in flash memory and perpetual calendar
- NEMA4 / IP65 panel protection rating
- COM2 RS-485 2W supports MPI 187.5K
- Built-in power isolation protection
Specifications:
| display | Display | 7” TFT |
| Resolution | 800 x 480 | |
| Brightness (cd/m2) | 450 | |
| Contrast | 500;1 | |
| Backlight type | LED | |
| Backlight life | >30,000 hours | |
| Display color | 16M | |
| LCD viewing angle (T/B/L/R) | 70/50/70/70 | |
| Touch panel | Type | 4-wire resistance |
| Touch accuracy | Action area Length (X) ± 2%, Width (Y) ± 2% | |
| Memory | Flash (Flash) | 128 MB |
| Memory (RAM) | 128 MB | |
| Processor | ARM RISC | |
| I/O port | USB Host | USB 2.0 x 1 |
| USB Client | N/A | |
| Ethernet network | 10/100 Base-T | |
| Serial interface | COM1: RS-232 | |
| COM2: RS-485 2W/4W | ||
| RS-485 double isolation protection | N/A | |
| power supply | Input power | 24 VDC ± 20% |
| Power consumption | 450mA@12VDC;300mA@24VDC | |
| Power isolation | Built in | |
| Withstand voltage | 500VAC (1 minute) | |
| Insulation resistance | exceeds 50MΩat 500VDC | |
| Anti-vibration | 10 to 25Hz (X, Y, Z axis 2G 30 minutes) | |
| specification | PCB coating | N/A |
| Shell material | engineering plastic | |
| Dimensions | 200.4 x 146.5 x 34 mm | |
| Opening size | 192 x 138 mm | |
| Weight | about 0.52 kg | |
| Installation method | Panel installation | |
| Operating environment | Degree of protection | NEMA4 / IP65 Compliant Front Panel |
| Storage ambient temperature | -20° ~ 60°C (-4° ~ 140°F) | |
| Operating ambient temperature | 0° ~ 50°C (32° ~ 122°F) | |
| Relative ambient humidity | 10% ~ 90% (non-condensing) | |
| Certification | CE | meets CE certification standards |
| Software | EBPro V6.08.01 or Updated version |
| Part Number | TK8072iP |
|---|---|
| Manufacturer | Weinview Co. Ltd |
| Weight (KG) | 2.000000 |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
