Water Flow Hall Effect Sensor YF-S401 (0.3-6L/Min)

SKU
MD-00463
PKR670.00
Quantity: 47
Water Flow Hall Effect Sensor YF-S401 (0.3-6L/Min)
  • Buy 3 for PKR636.50 each and save 5%
  • Buy 10 for PKR616.40 each and save 8%
  • Buy 50 for PKR569.50 each and save 15%

Water flow sensor consists of a plastic valve body, a water rotor, and a hall effect sensor - when water flows through, the internal rotator will change its speed with different rate of flow and hall effect sensor outputs the corresponding pulse signal. Use with laser cutters or CNC to measure if and how much water is flowing through laser tube or CNC spindle for cooling.

SPECIFICATIONS:

  1. Working Voltage: DC 5V~24V
  2. Maximum Working Current: 15mA @ 5V DC
  3. Flow Rate Range: 0.3~6L/min
  4. Connection: 6mm (external diameter)
  5. Inlet Water Pipe Diameter: 2.5-4mm
  6. Load Capacity: ≤10mA (DC 5V)
  7. Liquid Temperature: ≤120℃
  8. Operating Humidity: 35%~90%RH
  9. Water Pressure: ≤2.0MPa
  10. Storage Temperature: -25~+ 80℃
  11. Storage Humidity: 25%~95%RH

PIN CONFIGURATIONS:

  1. Red: Power In
  2. Black: Ground
  3. Yellow: Signal Output

PACKAGE INCLUDES:

  1. 1 X Water Flow Hall Effect Sensor YF-S401 (0.3-6L/Min)
Part Number YF-S401
Weight (KG) 0.020000
Manufacturer SeeedStudio
Product Availability In Stock
Voltage (Min) 5V
Voltage (Max) 24V
Power NA
Current (A) 15m
Display Resolution (Pixels) NA
Frequency NA
Output Type NA
Range 0.3-6L/Min
Temperature Range (Min) -40°C
Measurement Time NA
Sensor Type Water Flow Hall Effect Sensor
Baud Rate NA
Interface NA
Diameter NA
Size (mm) NA
