Vishay Semiconductors - High Power Infrared Emitting Diode NIR (TSAL5300)
SKU
MD-01113
PKR380.00
Quantity: 0
TSAL5300 is an infrared, 940 nm emitting diode in. GaAlAs/GaAs technology with high radiant power molded in a blue-gray plastic package. FEATURES.
- Buy 5 for PKR345.00 each and save 9%
- Buy 25 for PKR295.00 each and save 22%
- Buy 100 for PKR230.00 each and save 39%
- Buy 500 for PKR185.00 each and save 51%
Category: Light Emitting Diode (LED)
| Product Category: | Infrared Emitters | |
| Manufacturer: | Vishay | |
| RoHS: |  Details |
|
| Wavelength: | 950 nm | |
| Radiant Intensity: | 350 mW/sr | |
| If - Forward Current: | 100 mA | |
| Vf - Forward Voltage: | 1.6 V | |
| Power Rating: | 210 mW | |
| Maximum Operating Temperature: | + 100 C | |
| Minimum Operating Temperature: | - 55 C | |
| Package / Case: | T-1 3/4 | |
| Series: | TSAL | |
| Packaging: | Bulk | |
| Brand: | Vishay Semiconductors | |
| Height: | 8.7 mm | |
| Illumination Color: | Infrared | |
| Length: | 5.8 mm | |
| Lens Dimensions: | 5 mm x 5 mm x 7.7 mm | |
| Lens Shape: | Circular | |
| Factory Pack Quantity: | 4000 | |
| Viewing Angle: | 22 deg | |
| Vr - Reverse Voltage: | 5 V | |
| Width: | 5.8 mm | |
| Unit Weight: | 0.012346 oz |
| Part Number | TSAL5300 |
|---|---|
| Manufacturer | Vishay |
| Weight (KG) | 0.005000 |
