Ultimaker: Blue PET CF NFC Filament 2.85mm 750g for 3D Printer - 234522
SKU
MD-02351
PKR 67,000.00
🔥 High Demand Allocation:
2 Units
⚠️ Limited Quantity Remaining
Related Products
Category: Filaments
UltiMaker PET CF Blue is an engineering-grade, carbon fiber-reinforced composite filament designed to build exceptionally rigid and chemically resistant components. By combining a moisture-resistant PET matrix with structural carbon fiber reinforcement, it enables the fabrication of parts with high dimensional stability.
The industrial matte blue finish features a unique composite fiber texture that beautifully masks print layer lines. Beyond its mechanical performance, this colored carbon fiber variation allows engineers to visually color-code distinct elements in multi-component assemblies or distinct factory environments. Printed components can also be post-annealed in a programmable oven to achieve superior thermal and structural metrics.
Color Match & Visual Properties
- Official Color Name: Blue
- Industry Standard Match: RAL 5009 (Azure Blue)
- Surface Finish: Matte finish with a deep industrial hue and visible dark carbon matrix micro-fibers.
Targeted Applications (Blue Option)
The blue profile is uniquely suited for specialized industrial deployments:
- Color-coded component identification in intricate multi-material assemblies.
- Factory floor tooling, jigs, and custom manufacturing fixtures requiring high visibility.
- End-of-arm robotic tooling that needs a high strength-to-weight ratio paired with a distinct color schema.
- Pneumatic mounting brackets and functional prototypes undergoing fluid exposure.
Technical Specifications Matrix (Blue)
| Property Attribute | Out-of-Box (Unannealed) | Post-Oven Treated (Annealed) |
|---|---|---|
| Net Spool Weight | 750 grams | — |
| Filament Diameter | 2.85 mm ± 0.1 mm | — |
| Est. Filament Length | ~85 meters | — |
| Flexural Strength | ~100 MPa | ~130 MPa (+30% Performance) |
| Flexural Modulus / Stiffness | ~6000 MPa | ~6600 MPa (+10% Performance) |
| Heat Deflection Temp (HDT) | 76°C | 181°C (Thermal Stability Extreme) |
| Material Hardness | 76 Shore D | 81 Shore D |
Mandated Hardware Requirements (Frontend Alerts)
- Required Print Core: UltiMaker Print Core CC (0.4mm or 0.6mm). Warning: Carbon fiber is highly abrasive; printing with standard brass AA cores will permanently damage the nozzle system.
- Printer Compatibility: Fully optimized for UltiMaker S3, S5, S7, Factor 4, and Factor 4+ platforms.
- Support Material Options: Pairs with UltiMaker PVA (soluble) or UltiMaker Breakaway for structural complex dual-extrusion geometries
| Part Number | 234522 |
|---|---|
| Manufacturer | Ultimaker |
| Weight (KG) | 1.100000 |
| Material | NA |
| Packing Unit | 1 Piece |
| Product Availability | Available on Demand |
