u-blox: Automotive GNSS Application Board Evaluation Kit with ZED-F9K - C100-F9K
SKU
MD-02308
Special Price
PKR 82,500.00
was
PKR 98,500.00
The u-blox C100-F9K is a plug-and-play prototyping kit built for high-precision automotive tracking. Featuring the ZED-F9K module, it combines multi-band RTK with advanced 3D Inertial Dead Reckoning. This board gives engineers, developers, and robotics experts centimeter-level positioning data in real-time.
🔥 High Demand Allocation:
1 Units
⚠️ Limited Quantity Remaining
Related Products
Category: GPS & GSM Module
u-blox C100-F9K Automotive GNSS Application Board Kit
Overview
The u-blox C100-F9K application board is a high-precision, turn-key testing platform designed for automotive developers, fleet engineers, and autonomous robotics creators. [1]
By pairing a multi-band satellite receiver with an onboard Inertial Measurement Unit (IMU), this kit bridges the gap between sky and road. It allows you to test real-world driving scenarios under the toughest conditions—such as deep urban canyons, tunnels, and dense tree canopies—without ever losing track of your vehicle. It is the ultimate tool to evaluate lane-level tracking accuracy before moving your project to final production
Key Features
- Lane-Level Accuracy: Combines multi-band GNSS with RTK corrections for reliable, inches-tight tracking.
- Automotive Dead Reckoning (ADR): Built-in IMU sensors (gyros/accelerometers) keep tracking when satellite signals disappear.
- Plug-and-Play Design: Connects straight to your PC via USB or into vehicle networks using the 14-pin breakout cable.
- Native CAN-bus Integration: Easily reads vehicle speed and wheel tick data for perfect navigation modeling. [1, 2, 3, 4]
What’s in the Box?
Every retail kit comes packed with everything you need to start testing immediately:
- 1x C100-F9K application board (with integrated ZED-F9K module)
- 1x Active multi-band GNSS antenna (Required but not included)
- 1x 14-pin connector breakout cable (for external vehicle sensors)
- 1x USB interface cable
- Hardware jumpers for custom pin configuration
- Quick start welcome guide
Technical Specifications
| Feature [1, 2, 3] | Specification |
|---|---|
| GNSS Module | Integrated u-blox ZED-F9K |
| Supported Satellite Bands | GPS (L1C/A, L2C), GLONASS (L1OF, L2OF), GALILEO (E1B/C, E5b), BeiDou (B1I, B2I) |
| Positioning Accuracy | Up to 0.01 m (1 cm) + 1 ppm CEP (with RTK network correction) |
| Dead Reckoning Tech | 3D Automotive Dead Reckoning (ADR) with internal IMU |
| Update Rate | Up to 30 Hz (RTK + ADR) |
| Time-To-First-Fix (TTFF) | Cold Start: 24 seconds | Hot Start: 1 second |
| Data Interfaces | USB 2.0 (Micro-B), UART (TTL), I2C, SPI |
| Vehicle Sensor Inputs | CAN-bus, Wheel Tick, Direction / Reverse Pin (via 14-pin connector) |
| Input Voltage | 5V DC via USB or External Pins |
| Operating Temperature | -40°C to +85°C (Industrial Grade) |
Perfect For:
- Autonomous Driving Systems & ADAS Prototyping
- Unmanned Ground Vehicles (UGVs) & Delivery Robots
- High-End Fleet Management & Asset Tracking
- Automotive Telematics Testing [1]
| Part Number | C100-F9K |
|---|---|
| Manufacturer | United Automation |
| Weight (KG) | 0.300000 |
| Packing Unit | 1 Piece |
| Product Availability | Available on Demand |
