Traco Power: Isolated DC/DC Converter 9-36Vin +/-15V 400mA 12W - TEL 12-2423WI

SKU
MD-01783
PKR7,400.00
Quantity: 5
  • Buy 3 for PKR7,030.00 each and save 5%
  • Buy 10 for PKR6,808.00 each and save 8%

The TEL 12WI is a 12 Watt DC/DC converter series which comes in an ultra compact DIP-16 metal package. The design purpose was to miniaturized low power DC/DC converters to the maximum without sacrificing high efficiency. They solidify the new standard for power density with 3,61 W/cm3 and effectively double the power density compared to 12 Watt converters in DIP-24 package. The TEL 12WI and offers a wide 4:1 input voltage range and features a high efficiency of up to 88% which enables an operation temperature of up to +65°C at full load and up to 85°C with 50% load. The converters also have an internal input filter to comply with conducted emission standard EN 55032 class A. Overall they feature an economical solution for space critical and cost sensitive applications in instrumentation, IT and industrial electronics.

Product Attribute Attribute Value
TRACO Power
Isolated DC/DC Converters
2 Output
12 W
24 V
9 V
36 V
15 V
400 mA
- 15 V
400 mA
1.5 kV
- 40 C
+ 85 C
Through Hole
DIP-16
23.8 mm
13.7 mm
10.2 mm
Industrial
Isolated
TEL 12WI
Dimensions: 23.8 mm x 13.7 mm x 10.2 mm
Input Voltage: +/- 9 V to +/- 36 V
Packaging: Tube
Product Type: Isolated DC-DC Converters
Factory Pack Quantity: 10
Subcategory: DC-DC Converter
Part Number TEL-12-2423WI
Manufacturer TRACO Power
Weight (KG) 0.010000
Product Availability In Stock
