Temperature Sensor IC LM35DZ

SKU
MD-00362
PKR80.00
Quantity: 14
The LM35 series are precision integrated-circuit with an output voltage linearly- proportional to the Centigrade temperature.
  • Buy 3 for PKR75.00 each and save 6%
  • Buy 10 for PKR72.00 each and save 10%
  • Buy 50 for PKR70.00 each and save 13%

The LM35 series are precision integrated-circuit  with an output voltage linearly- proportional to the Centigrade temperature. The LM35 device has an advantage over linear  temperature sensors calibrated in Kelvin, as the user is not required to subtract a large constant voltage from the output to obtain convenient Centigrade. The LM35 device does not require any external calibration or trimming to provide typical accuracies of ±¼°C at room temperature and ±¾°C  over a full −55°C to 150°C temperature range.

FEATURES:

  1. Calibrated Directly in Celsius (Centigrade)
  2. Linear + 10-mV/°C Scale Factor
  3. 0.5°C Ensured Accuracy (at 25°C)
  4. Rated for Full −55°C to 150°C Range
  5. Suitable for Remote Applications
  6. Low-Cost Due to Wafer-Level Trimming scaling
  7. Low Self-Heating, 0.08°C in Still Air
  8. Low-Impedance Output, 0.1 Ω for 1-mA Load
  9. Non-Linearity Only ±¼°C Typical

PIN CONFIGURATIONS:

 Pin configurations

RELATED DOCUMENTS:

  1. Temperature Sensor IC LM35DZ Datasheet.

APPLICATIONS:

  1. Power Supplies
  2. Battery Management
  3. HVAC
  4. Appliances

PACKAGE INCLUDES:

  1. 1 X Temperature Sensor IC LM35DZ
Part Number LM35DZ
Weight (KG) 0.000065
Manufacturer Made in China
Model Number LM35DZ
Voltage (Min) 4V
Voltage (Max) 30V
Power NA
Current (A) 65m
Temperature Range (Min) -55°C
Temperature Range (Max) 150°C
Memory NA
SMD_Package DIP TO-92
