Step'n Components: Pin Insertion & Removal Tool (Red/White) – 11-16736 , M81969/14-11
SKU
MD-02358
PKR 2,350.00
🔥 High Demand Allocation:
4 Units
⚠️ Limited Quantity Remaining
Category: Others
The Step'n Components 11-16736 (M81969/14-11) is a dual-ended, all-plastic hand tool engineered for the damage-free installation and extraction of Size 20 pin and socket contacts. Sourced widely by aviation parts supply stores like Aircraft Spruce, this professional tool features a 100% solid molded plastic composition specifically chosen to protect the delicate interfacial seals and plastic connector blocks found in rear-release aerospace connectors. Featuring a distinct Red/White color-coded body for instant wire-gauge identification, it serves as a critical asset for avionics technicians executing wiring harness assembly, MRO operations, and electrical troubleshooting without scratching the surrounding connector infrastructure.
Key Features & Benefits
- All-Plastic Construction: Zero metal content protects soft internal connector geometries, wire insulation, and delicate backshell seals from structural scratching or marring. [1, 2]
- Dual-Action Workflows: Incorporates both an insertion side (Red) and an extraction side (White) on a single piece of hardware to minimize toolkit weight and maximize efficiency. [1]
- Targeted System Compatibility: Optimized explicitly for rear-release military circular and rectangular connector networks. [1, 2]
- QPL Military Standard: Manufactured by Step'n Components to fully comply with official military specification QPL guidelines. [1, 2]
Technical Specifications
| Attribute | Specification Details |
|---|---|
| Manufacturer | Step'n Components (STEP'N CO) |
| Manufacturer Part Number | 11-16736 |
| Mil-Spec Cross Reference | M81969/14-11 |
| Compatible Contact Size | Size 20 AWG |
| Material Composition | 100% Solid Molded Plastic |
| Color Coding | Red / White (Red = Install / White = Remove) |
| Compatible Connector Series | MIL-DTL-26482 Series II, AS81703 Series III, MIL-DTL-83733, MIL-DTL-83723 Series II & III, AS50151, AS81714 |
| Country of Origin | USA |
| Part Number | M81969/14-11 |
|---|---|
| Weight (KG) | 0.010000 |
| Material | NA |
| Packing Unit | 1 Piece |
| Product Availability | Available on Demand |
