SONOFF: TH Origin Smart Temperature and Humidity Monitoring Switch - TH16
SONOFF TH Origin (the upgrade version of TH10/TH16) is a smart temperature and humidity monitoring switch with ESP32 chip, it keeps monitoring the temperature and humidity in real time, once they reach your preset threshold or the device's on/off state changes, you will receive the push notification on the phone. SONOFF TH Origin supports 20A/16A max loads, compatible with more home appliances. TH Origin support to check 6-Month Temp & Humi historical data accurate to the hour. In the smart scene, temperature, humidity, on, off support setting as the trigger, on, off, invert as execute actions. Support adding SONOFF devices to Home Assistant for control and automation through eWeLink add-on.
SONOFF TH Origin supports three kinds of temperature monitor and humidity monitor sensors—THS01 Temp & Humi Sensor, DS18B20 waterproof Temp sensor, and MS01 Soil Moisture Sensor. The sensor connector is upgraded to RJ9, supporting hot-plugging making the connection more stable and reliable. So TH Origin has wide application scenes, like heated swimming pool, irrigation system, fermentation room, reptile terrarium, greenhouse grown, etc.
The RL560 sensor extension cable can connect the SONOFF temperature and humidity sensors to extend your device's distance. THS01, DS18B20 can be extended to 60M, and MS01 Soil Moisture Sensor can be extended to 10M.
THS01 Sensor
- Sensor Type: Temperature & Humidity sensor
- Connector type: RJ9 4P4C
- Temperature Measuring Range: –40℃~+85°C
- Humidity Measuring Range: 0~100%RH
- Cable Length: 50cm
DS18B20 Sensor
- Sensor Type: Waterproof temperature sensor
- Connector type: RJ9 4P4C
- WorkigTemperature: -55℃~+125℃
- Length: 50cm
MS01 Sensor
- Sensor Type: Soil Moisture Sensor
- Humidity Measuring Range: 0~100%RH
- Operating Temperature Range: 0℃~60°C
- Cable Length: 50cm
RL560 Sensor Extension Cable
- Conductor resistance: max.10Ω
- Insulation resistance: min.5MΩ
- Length: 5m cable length & Max. 60m extendable length.
Additional information
| TH Origin |
16A, 20A |
|---|---|
| Model |
THR316/THR320 |
| MCU |
ESP32 |
| THR316 Input/Output |
100-240V~ 50/60Hz 16A Max |
| THR320 Input/Output |
100-240V -50/60Hz 20A Max |
| Wi-Fi |
IEEE 802.11 b/g/n 2.4GHz |
| TH Origin Working Humidity |
5%-95%RH,non-condensing |
| TH Origin Working Temperature |
-10°C~40°C(14℉~104℉) |
| Certification |
TUV/CE/UKCA/WWA/FCC/RoHS/SRRC |
| Security Mode |
WPA/WPA2 |
| Supported Sensor |
THS01, DS18B20, MS01 |
| THS01 Working Temp |
–40℃~+85°C(-40℉~185℉) |
| THS01 Humi Measuring Range |
0~100%RH |
| DS18B20 WorkigTemp |
-55℃~+125℃(-67℉~257℉) |
| MS01 Humi Measuring Range |
0~100%RH |
| MS01 Operating Temp Range |
0℃~60°C(32℉~140℉) |
| RL560 Conductor Resistance |
Max.10Ω |
| RL560 Insulation Resistance |
Min.5MΩ |
| Works with |
Amazon Alexa, Google Assistant |
| Casing Material |
PC V0 |
| Color |
White |
| Product Size |
98x54x27.5mm |
| Part Number | TH16 |
|---|---|
| Manufacturer | iTead Studio |
| Weight (KG) | 0.050000 |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
