SMC: Reed Switch Electric Actuator Switch - D-B54
SKU
MD-01733
Categories: Relays, Switching Module, Switches and Keypads
SMC Band Mounting Proximity Reed Switch
SMC proximity reed switch which is band mounting and are designed for use with CG1, CLA, NCG and NCM series of Cylinders
Specifications
| Attribute | Value |
| Manufacturer Series | D-B |
| Compatible With | CG1, CLA, NCG, NCM |
| Type | Reed Switch |
| LED Indicator | Yes |
| Voltage Rating | 24 V dc, 100 V ac, 110 V ac, 200 V ac, 220 V ac |
| Voltage Drop | <2.4V |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -10°C |
| Part Number | D-B54 |
|---|---|
| Manufacturer | SMC Corporation |
| Weight (KG) | 0.050000 |
| Product Availability | Available on Demand |
