Siemens: SIMATIC Smart Line 700 HMI 7" V3 Touch Screen - 6AV6648-0CC11-3AX0
SKU
MD-01794
PKR107,000.00
Available in 15-30 Days
- Buy 3 for PKR101,650.00 each and save 5%
- Buy 10 for PKR98,440.00 each and save 8%
Categories: LCDs, Display Screens LCDs, Human Machine Interface HMI
SIMATIC HMI SMART 700 IE V3, SMART Panel, Touch operation, 7" widescreen TFT display, 65536 colors, RS422/485 interface, Ethernet (RJ45) interface, host USB type A, RTC support, with CE certificate, configurable from WinCC flexible SMART; contains open-source software, which is provided free of charge see enclosed CD
| Dimensions | ||
| Width of the housing front | 209 mm | |
| Height of housing front | 155 mm | |
| Mounting cutout, width | 192 mm | |
| Mounting cutout, height | 138 mm | |
| Overall depth | 39 mm | |
| Weights | ||
| Weight without packaging | 765 g | |
| General information | ||
| Product type designation | SIMATIC HMI SMART 700 IE V3 | |
| Display | ||
| Design of display | TFT | |
| Screen diagonal | 7 in | |
| Display width | 154.1 mm | |
| Display height | 85.9 mm | |
| Number of colors | 65 536 | |
| Resolution (pixels) | ||
| ● Horizontal image resolution | 800 Pixel | |
| ● Vertical image resolution | 480 Pixel | |
| Backlighting | ||
| ● MTBF backlighting (at 25 °C) | 20 000 h | |
| Supply voltage | ||
| Type of supply voltage | DC | |
| Rated value (DC) | 24 V | |
| permissible range, lower limit (DC) | 19.2 V | |
| permissible range, upper limit (DC) | 28.8 V | |
| Input current | ||
| Current consumption (rated value) | 200 mA | |
| Current consumption, max. | 340 mA | |
| Starting current inrush I²t | 0.1 A²·s | |
| Processor | ||
| Processor type | ARM, 600 MHz | |
| Part Number | 6AV6648-0CC11-3AX0 |
|---|---|
| Manufacturer | Siemens |
| Weight (KG) | 1.200000 |
| Product Availability | Available on Demand |
