RD6-W Series Phase Protection Relay (Chinese Language
PKR 5,600.00
Only 2 left
SKU
MD-00113
- Buy 3 for PKR 5,320.00 each and save 5%
- Buy 10 for PKR 5,152.00 each and save 8%
The RD6-W series uses the current high end microcomputer control technology, not only has the under voltage,Phase, Phase sequence protection. And equipped with function keys can be set function according to the different use environment. Compared with similar products, RD6-W series has the advantages of low power consumption, wide heat is small, high measuring precision and the use of voltage range.
RD6-W is multi-functional monitoring and protection device which includes timing, counting and voltage show, over-voltage and under-voltage protection, open phase protection and phase sequence protection.It uses advanced microprocessor chip and nonvolatile storage technology. LCD display is easy to operateIt can record working times and working hours, fault times and hours, show the current supply voltage . Cut off power to protect the equipment when meet over-voltage and under-voltage, phase loss and phase reversal faults.
FEATURES:
- Liquid crystal display directly the various state of three-phase voltage
- The scope of protection of AC200V ~ AC500V, phase failure and phase unbalance,overvoltage, undervoltage can be set to detect.
- Wide voltage operation counting, timing function.
- Power supply voltage: 200-500VAC
- Voltage display: 150V-500V
- Max. counting times: 999999 times
- Max. timing: 9999 hours 59 minutes
- Max. speed: 5HZ/S
- Contact output capacity: 2A 250VAC
- Data keeping: 10 years
RELATED DOCUMENTS:
PACKAGE INCLUDES:
- 1 X RD6-W Series Phase Protection Relay
| Part Number | RD6-W |
|---|---|
| Manufacturer | Made in China |
| Weight (KG) | 0.004000 |
| Product Availability | In Stock |
