Portable Electronic Weight Sensor-Load Cell (5Kg)
Special Price
PKR 750.00
Regular Price
PKR 950.00
Only 4 left
SKU
MD-00293
This Portable Electronic Weight Sensor can translate up to 5kg of pressure (force) into an electrical signal.
This Portable Electronic Weight Sensor can translate up to 5kg of pressure (force) into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to, and proportional of, the strain (e.g. pressure or force) applied to the bar. With this gauge you will be able to tell just how heavy an object is, if an object’s weight changes over time, or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.
SPECIFICATIONS:
| Product Name | Portable Electronic Weight Sensor-Load Cell |
| Rated Load | 5Kg /11lb |
| Rated Output | 1.2±0.1mV/V |
| Input Resistance | 1066 ± 20 Ohm |
| Output Resistance | 1000 ± 20 Ohm |
| Insulation Resistance | 2000 Ohm |
| Compensated Temperature Range | -10°C~+50°C |
| Safety Overload | 120%F.S |
| Recommend Excitation Voltage | DC 5V |
| Max Excitation Voltage | DC 10V |
| Cable Length | 245mm/9.6'' |
| Material | Aluminium Alloy |
| Red | E+ |
| Black | E- |
| White | S+ |
| Green | S- |
APPLICATIONS:
- Strain measurement
- Digital and Analog Electronic Weighing scales
- Weight Balancing Machines
PACKAGE INCLUDES:
- 1 X Portable Electronic Weight Sensor-Load Cell (5Kg)
| Part Number | NA |
|---|---|
| Weight (KG) | 0.021000 |
| Manufacturer | Made in China |
| Voltage (Min) | 5V |
| Voltage (Max) | 10V |
| Output Voltage | NA |
| Power | NA |
| Current (A) | NA |
| Frequency | NA |
| Load Cell (kg) | 5 |
| Output Type | Voltage Signal |
| Range | 5Kg |
| Temperature Range (Min) | -20°C |
| Temperature Range (Max) | 65°C |
| Operating System | NA |
| Resistance Value (Ohm) | NA |
| Baud Rate | NA |
| Interface | NA |
| Num of Pin's | 4 |
| Size (mm) | 12.7 x 12.7 x 75 |
