Phoenix Contact Single Relay - REL-IR4/L-230AC/4X21

FEATURES:

1. Test voltage relay winding/relay contact: 2.5 kVrms (50 Hz, 1 min.)
2. Test voltage PDT/PDT: 2 kVrms (50 Hz, 1 min.)
3. Operating mode: 100% operating factor
4. Degree of protection: RT I
5. Mechanical service life: Approx. 2 x 107 cycles
6. Designation: Air clearances and creepage distances between the power circuits
7. Standards/regulations: IEC 60664
8. Rated insulation voltage: 250 V AC
9. Pollution degree: 2
10. Overvoltage category:            II
11. Designation: Standards/regulations
12. Standards/regulations: IEC 61810
13. Mounting position: any

SPECIFICATION:

1. Nominal input voltage UN: 230 V AC
2. Input voltage range in reference to UN: see diagram
3. Typical input current at UN: 6.5 mA
4. Typical response time: 5 ms ... 15 ms (depending on phase relation)
5. Typical release time range: 5 ms ... 20 ms (depending on phase relation)
6. Status display: Yellow LED
7. Contact type: 4 PDTs
8. Contact material: AgNi
9. Maximum switching voltage: 250 V AC/DC
10. Minimum switching voltage: 5 V (At 24 mA)
11. Min. switching current: 5 mA (at 24 V)
12. Maximum inrush current: 16 A (20 ms, N/O contact)
13. Limiting continuous current: 6 A
14. Switching capacity min: 0.12 W

PARAMETERS:

1. Width: 21.2 mm
2. Height: 35.6 mm
3. Depth: 27.5 mm

PACKAGE INCLUDES:

1. 1X Phoenix Contact Single Relay - REL-IR4/L-230AC/4X21
