Phoenix Contact Single Relay-REL-IR4/L- 24AC/4X21 - 2903686

FEATURES:

1. Test voltage relay winding/relay contact: 2.5 kVrms (50 Hz, 1 min.)
2. Test voltage PDT/PDT: 2 kVrms (50 Hz, 1 min.)
3. Operating mode: 100% operating factor
4. Degree of protection: RT I
5. Mechanical service life: Approx. 2 x 10⁷ cycles
6. Designation: Air clearances and creepage distances between the power circuits
7. Standards/regulations: IEC 60664
8. Rated insulation voltage: 250 V AC
9. Pollution degree: 2
10. Overvoltage category:            II
11. Designation: Standards/regulations
12. Standards/regulations: IEC 61810
13. Mounting position: any

SPECIFICATION:

1. Nominal input voltage UN: 24V AC
2. Typical input current at UN: 66 mA
3. Typical response time: 5 ms ... 15 ms (depending on phase relation)
4. Typical release time range: 5 ms ... 20 ms (depending on phase relation)
5. Status display: Yellow LED
6. Contact type: 4 PDTs
7. Contact material: AgNi
8. Maximum switching voltage: 250 V AC/DC
9. Minimum switching voltage: 5 V (At 24 mA)
10. Min. switching current: 5 mA (at 24 V)
11. Maximum inrush current: 16 A (20 ms, N/O contact)
12. Limiting continuous current: 6 A
13. Switching capacity min: 0.12 W

PARAMETERS:

1. Width: 21.2 mm
2. Height: 35.6 mm
3. Depth: 27.5 mm

PACKAGE INCLUDES:

1. 1 X Phoenix Contact Single Relay-REL-IR4/L- 24AC/4X21
