Phoenix Contact PrintedCircuit Board Connector MCVW 1.5/3-STF-3.5 (1863013)

Phoenix Contact Control Cabinet Solutions offer flexibility, innovation, and cost effective products for every application. From Power Supplies, DIN Rail Terminal Blocks,  Relays, Circuit Breakers, and lighting and more that Phoenix Contact can offer a single source solution for all control cabinet needs. Control cabinet solutions are designed to the required standards and directives, allowing the finished products to meet the highest requirements.

 FEATURES:

1. Range of articles: MCVW 1,5/..-STF
2. Type of contact: Female connector
3. Number of positions: 3
4. Insulating material group: I
5. Rated surge voltage (III/3): 2.5 kV
6. Rated surge voltage (III/2): 2.5 kV
7. Rated surge voltage (II/2): 2.5 kV
8. Rated voltage (III/3): 160 V
9. Rated voltage (III/2): 160 V
10. Rated voltage (II/2): 320 V
11. Connection in acc. with standard: EN-VDE
12. Nominal current IN: 8 A
13. Maximum load current: 8 A (with 1.5 mm² conductor cross section)
14. Internal cylindrical gage: A1

CLASSIFICATIONS:

eCl@ss:

1. eCl@ss 4.0: 272607xx
2. eCl@ss 4.1: 27260701
3. eCl@ss 5.0: 27260701
4. eCl@ss 5.1: 27260701
5. eCl@ss 6.0: 27260704
6. eCl@ss 7.0: 27440402
7. eCl@ss 8.0: 27440309
8. eCl@ss 9.0: 27440309

 ETIM:

1. ETIM 3.0: EC001121
2. ETIM 4.0: EC002638
3. ETIM 5.0: EC002638
4. ETIM 6.0: EC002638

UNSPSC:

1. UNSPSC 6.01: 30211810
2. UNSPSC 7.0901: 39121409
3. UNSPSC 11: 39121409
4. UNSPSC 12.01: 39121409
5. UNSPSC 13.2: 39121409

RELATED DOCUMENTS:

1. DataSheet

PARAMETERS:

1. Pitch: 3.5 mm
2. Dimension a: 7 mm

PACKAGE INCLUDES:

1. 1 X Phoenix Contact PrintedCircuit Board Connector MCVW 1.5/3-STF-3.5 (1863013)
