Phoenix Contact - Industrial Ethernet Switch FL SWITCH SF 8TX (2832771)

These unmanaged switches provide a unique combination of affordability and maximum immunity against industrial environments. System startups and ongoing maintenance are reduced through a complete range of unmanaged switch functions such as redundant power supplies, alarm contact, auto negotiation and cable auto crossing. The FL Switch SF line provided connectivity to 8 or 16 copper 10/00 Mbps ports, including configurations, which support one or two multi-mode 100 Mbps glass-fiber ports.

FEATURES:

1. Operating Temp: 0°C to +55°C (+32°F to +131°F)
2. IP20 Protection
3. Voltage Range: 18.5 VDC to 30.2 VDC
4. Transmission Speed: 10/100 Mbps on RJ 45 Ports and 100 Mbps on Fiber-Optic Ports
5. Maximum Network Segment Expansion: 100 m for Twisted Pair Cabling and up to 2 km for Glass-Fiber Cabling
6. Alarm Contacts
7. Autocross Function
8. DIN-Rail Mounted

SPECIFICATIONS:

1. Accessory Type: Industrial Ethernet Switch
2. Brand/Series:  SF Series
3. Current, Supply: 200 mA
4. Mounting Type: DIN Rail
5. Number of Ports: 8
6. Port, Type: RJ45
7. Primary Type: Ethernet Switch
8. Protocol Type: 10/100 Mbit/s (RJ45)
9. Special Features: Auto-Negotiation, Auto-Crossing, Store and Forward
10. Type: Unmanaged Switch
11. Voltage, Supply: 24 VDC

INTERFACE:

1. Interface 1: Ethernet (RJ45)
2. No. of ports: 8 (RJ45 ports)
3. Connection method: RJ45
4. Note on connection method: Auto negotiation and auto crossing
5. Transmission physics : Ethernet in RJ45 twisted pair
6. Transmission speed: 10/100 MBit/s
7. Transmission length: 100 m (per segment)
8. Signal LEDs: Data receive, link status
9. Interface 4: Potential-free signaling contact
10. Connection method: Plug-in/screw connection via COMBICON

CLASSIFICATIONS:

eCl@ss:

1. eCl@ss 4.0: 27250501
2. eCl@ss 4.1: 27250501
3. eCl@ss 5.0: 27250501
4. eCl@ss 5.1: 27250501
5. eCl@ss 6.0: 19170106
6. eCl@ss 7.0: 19170106
7. eCl@ss 8.0: 19170106
8. eCl@ss 9.0: 19170106

ETIM:

1. ETIM 2.0: EC000734
2. ETIM 3.0: EC000734
3. ETIM 4.0: EC000734
4. ETIM 5.0: EC000734

UNSPSC:

1. UNSPSC 6.01: 43172015
2. UNSPSC 7.0901: 43201404
3. UNSPSC 11: 43172015
4. UNSPSC 12.01: 43201410
5. UNSPSC 13.2: 43201410

RELATED DOCUMENTS:

1. DataSheet

PARAMETERS:

1. Depth: 30 mm
2. Width: 135 mm
3. Height: 94.3 mm

PACKAGE INCLUDES:

1. 1 X Phoenix Contact Industrial Ethernet Switch FL SWITCH SF 8TX (2832771)
