Orange Pi 2 Model H3 1.6GHz QuadCore Board With Built in Wifi

SKU
MD-00576
-9%
Special Price PKR9,850.00 was PKR10,860.00
Quantity: 0
The board is said to support Android 4.4 , Lubuntu, Debian, and Rasberry Pi Images.
  • Buy 3 for PKR9,360.00 each and save 5%
  • Buy 10 for PKR8,865.00 each and save 10%

It’s an open-source single-board computer. It can run Android 4.4 , Ubuntu, Debian, Rasberry Pi Image, it uses the AllWinner H3 SoC, and has 2GB DDR3 SDRAM.

FEATURES:

  1. SoC – Allwinner H3 quad core Cortex A7 1.6 GHz with ARM Mali-400MP2 GPU up to 600 MHz
  2. System Memory – 2GB DDR3
  3. Storage – 8GB eMMC, micro SD card slot, SATA interface (via a USB to SATA chip),
  4. Video Output – HDMI, AV port
  5. Audio I/O – HDMI, AV port, on-board microphone
  6. Connectivity – 10/100/1000M Ethernet, 802.11 b/g/n Wi-Fi (Realtek RTL8189ETV)
  7. USB – 4x USB 2.0 host ports, 1x micro USB OTG port
  8. Camera – CSI Interface
  9. Expansions – 40-pin Raspberry Pi Model A+/B+ (mostly) compatible header
  10. Debugging – 3-pin UART header for serial console
  11. Misc – IR receiver; Power, recovery, and upgrade buttons
  12. Power Supply – 5V/2A via barrel jack or micro USB OTG; Power and status LEDs
  13. Dimensions – 108 x 67 mm (Pi Plus is 108 x 60 mm)

SPECIFICATIONS:

­­­­­­CPU

H3 Quad-core Cortex-A7 H.265/HEVC 4K

GPU

·Mali400MP2 GPU @600MHz
·Supports OpenGL ES 2.0

Memory (SDRAM)

2GB DDR3 (shared with GPU)

Onboard Storage

TF card (Max. 64GB) / MMC card slot , up to 2T on 2.5 SATA disk
16GB EMMC Flash

Onboard Network

10/100/1000M Ethernet RJ45

Onboard WIFI

Realtek RTL8189ETV, IEEE 802.11 b/g/n

Video Input

A CSI input connector Camera:

Supports 8-bit YUV422 CMOS sensor interface

Supports CCIR656 protocol for NTSC and PAL

Supports SM pixel camera sensor

Supports video capture solution up to 1080p@30fps

Audio Input

MIC

Video Outputs

Supports HDMI output with HDCP

Supports HDMI CEC

Supports HDMI 30 function

Integrated CVBS

Supports simultaneous output of HDMI and CVBS

Audio Output

3.5 mm Jack and HDMI

Power Source

DC input can supply power, but USB OTG input don’t supply power

USB 2.0 Ports

Four USB 2.0 HOST, one USB 2.0 OTG

Buttons

Power Button(SW4), Recovery Button(SW3), Uboot Button(SW2)

Low-level peripherals

40 Pins Header,compatible with Raspberry Pi B+

GPIO(1x3) pin

UART, ground.

LED

Power led & Status led

Other

IR input

Supported OS

Android, Ubuntu, Debian, Rasberry Pi Image

PIN CONFIGURATIONS:

 PIN DIAGRAM

PACKAGE INCLUDES:

  1. 1 X Orange Pi 2 Model H3 1.6GHz QuadCore Board With Built in Wifi
Part Number NA
Weight (KG) 0.020000
Manufacturer BeagleBone
Voltage (V) 5
Current (A) 24m
Model Orange Pi 2 Model H3
Processor H3 Quad-core Cortex-A7 H.265/HEVC 4K
Operating System NA
Frequency 1.6GHz
Hardrive TF card (Max. 64GB) / MMC card slot , up to 2T on 2.5 SATA disk 16GB EMMC Flash
Wifi Yes
Bluetooth No
Output Port 3.5 mm Jack , HDMI,Four USB 2.0 HOST, one USB 2.0 OTG,10/100/1000M Ethernet RJ45
Num of Core Quad
Num of Ports NA
Size (mm) NA
