Optical Fiber Pigtail Single Mode 2 Meter - FC/UPC-SM-SX-0.9-2M
SKU
MD-02164
PKR350.00
Quantity: 45
- Buy 3 for PKR332.50 each and save 5%
- Buy 10 for PKR322.00 each and save 8%
Category: Wires and Cables
| Connector Type | FC UPC | Fiber Grade | G.657.A1 (Compatible with G.652.D) |
| Fiber Mode | OS2 9/125μm | Wavelength | 1310/1550nm |
| Insertion Loss | ≤0.25dB | Return Loss | ≥50dB |
| Min. Bend Radius (Fiber Core) | 10mm | Min. Bend Radius (Fiber Cable) | 10D/5D (Dynamic/Static) |
| Attenuation at 1310 nm | 0.36 dB/km | Attenuation at 1550 nm | 0.22 dB/km |
| Fiber Count | Simplex | Cable Diameter | 0.9mm |
| Cable Jacket | PVC | Polarity | A(Tx) to B(Rx) |
| Operating Temperature | -20~70°C | Storage Temperature | -40~80°C |
| Part Number | FC/UPC-SM-SX-0.9-2M |
|---|---|
| Weight (KG) | 0.010000 |
| Connector Type | NA |
| Num of Pin's | NA |
| Pitch | NA |
| PITCH | NA |
| Bandwidth | NA |
| Num of Ports | NA |
| Ports | NA |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
