Optical Biological Microscope with Binocular Head - XSZ-107B

SKU
MS-01085
PKR31,500.00
Available Quantity: 2

With a twist on a classic design this ALL METAL CONSTRUCTION dual light high power compound microscope with top & bottom LED lights enabling viewing of both translucent biological samples, and low magnification (4x and 10x objective) viewing of solid objects such as insects, flowers, coins and household specimens. Features a built in rechargeable battery and AC power adaptor for use both inside and outside, provides up to 15 hours use from a single charge.

This student microscope equipped with a mechanical stage which allows smooth and easy adjustment of slides left/right or backward/forward during observation as well as both coarse and fine focusing controls.

Mainly recommended for primary and middle school education, home schooling and for children over the ages of 11+, not recommended for high school/university level education and/or serious biological studies, for users on a limited budget can be used occasionally for faecal worm egg counting and soil biology.

Features:

  • All Metal Construction & GLASS Optics
  • Binocular Head
  • Pair of 10X eyepieces
  • 4X, 10X, 40X DIN Objectives
  • Magnification from 40X to 400X
  • Course & fine focusing
  • Mechanical stage (low position controls)
  • Upper & lower LED light sources
  • Condenser with iris diaphragm
  • Built-in rechargeable battery
  • Detachable AC adapter cord


Achromatic Objectives             4X,10X,40X(S),100X(S,Oil)
Eyepiece               Wide Field Eyepiece :WF10X,WF16X
Viewing head           Sliding Binocular Head Inclined at 45°
Stage                    Double Layer Mechanical Stage Size 140X140mm,Moving Range 75X45mm
Focusing                Coaxial Coarse and Fine Adjustment,Focusing Range 30mm,Focusing Interval 0.002mm
Condenser            Abbe NA=1.25 with lris Diaphragm&Filter
IIIumination          Halogen Lamp 220V/6V20W or 110V/6v20W ; (LED lam optional)
Part Number XSZ-107B
Manufacturer Made in China
Weight (KG) 8.000000
Packing Unit 1 Piece
Product Availability Available on Demand
