OMRON MEMS Thermal Sensors D6T-44L-06
- Buy 3 for PKR11,210.00 each and save 5%
- Buy 10 for PKR10,384.00 each and save 12%
- Buy 25 for PKR9,440.00 each and save 20%
Omron's D6T Series MEMS Thermal Sensors are a super-sensitive infrared temperature sensor that makes full use of Omron's proprietary MEMS sensing technology. Unlike typical pyroelectric human presence sensors that rely on motion detection, the D6T thermal sensor is able to detect the presence of stationary humans by detecting body heat, and can therefore be used to automatically switch off unnecessary lighting, air conditioning, etc. when people are not present. As the D6T sensor is also able to monitor the temperature of a room, it can also be used to continually maintain optimal room temperature levels, instantly sense unusual changes in temperature thereby detecting factory line stoppages, or discover areas of overheating for early prevention of fire outbreaks.
The D6T-44L-06 from Omron is a MEMS thermal sensor. It is small size, high accuracy, low noise, high sensitivity sensor that enables detection of stationary human presence by non contact temperature measurement.
FEATURES:
- 4 x 4 element type
- Superior noise immunity with a digital output
- High precision area temperature detection with low cross talk field of view characteristics
- Unique MEMS and ASIC technology achieve a high SNR
- Viewing angle in X direction is 44.2° and Y direction 45.7°
- Current consumption is typically 5mA
- I2C digital output
- Hot spot detection
- Variety of pixel arrays available
- Viewing Angle: X Direction :62.8°, X Direction :6.0°
CHRACTERSTICS:
|
Item |
D6T-44L-06 |
|
|
View angle *1 |
X direction |
44.2° |
|
Y direction |
45.7° |
|
|
Object temperature output |
Accuracy 1 |
±1.5°C max. |
|
Accuracy 2 |
±3.0°C max. |
|
|
Current consumption |
5 mA typical |
|
|
Item |
Specification |
|
Object temperature detection range *2 |
5 to 50°C |
|
Reference temperature detection range *2 |
5 to 45°C |
|
Output specifications |
Digital values that correspond to the object |
|
Output form |
Binary code (10 times the detected temperature |
|
Communications form |
I2C compliant |
|
Temperature resolution (NETD) |
0.14°C |
FUNTIONAL DIAGRAM:
PHYSICAL DIAGRAM:
RELATED DOCUMENTS:
PINCONFIGURATIONS:
|
Terminal |
Name |
Function |
|
1 |
GND |
Ground |
|
2 |
VCC |
Positive power supply |
|
3 |
SDA |
Serial data I/O line |
|
4 |
SCL |
Serial clock input |
APPLICATIONS:
- Energy-saving household appliances (lighting systems, refrigerators, microwave ovens, air conditioners, etc.)
- Building and office energy conservation systems
- Security systems
- Factory automation (food product temperature control, irregular temperature detection, etc.)
RELATED VIDEO:
PACKAGE INCLUDES:
- 1 X OMRON MEMS Thermal Sensors D6T-44L-06
| Part Number | D6T-44L-06 |
|---|---|
| Weight (KG) | 0.003750 |
| Manufacturer | OMRON electronics |
| Product Availability | In Stock |
| Voltage (Min) | 4.5V |
| Voltage (Max) | 5.5V |
| Output Voltage | NA |
| Power | NA |
| Current (A) | NA |
| Frequency | NA |
| Load Cell (kg) | NA |
| Output Type | NA |
| Range | NA |
| Temperature Range (Min) | 0°C |
| Temperature Range (Max) | 50°C |
| Operating System | NA |
| Resistance Value (Ohm) | NA |
| Baud Rate | NA |
| Interface | NA |
| Num of Pin's | NA |
| Diameter | NA |
| Size (mm) | 18x14x8.8mm |
