OMRON Digital Temperature Controller E5CZ-R2MT AC100-240

The E5CZ-R2MT AC100-240 is a Digital Temperature Controller with either temperature inputs or analog inputs and relay outputs. It offers a wide range of functions such as a loop break alarm (LBA), manual output and transfer output. The setting tool port provided as a standard feature for easy connection. The new protocol called Modbus is installed in the model with communications.

FEATURES:

1. Type: Temperature Controller (RTD, Type B, E, J, K, L, N, R, S, T, U)
2. Input Range: -200°C ~ 1800°C, 0 ~ 50mV
3. Output Type: Relay (3)
4. Control Method: On/Off, Proportional (PID)
5. Communications: Option Cards Available
6. Number Of Characters Per Row: 4, 4
7. Display Type: LCD - Dual Color Characters, Backlight
8. Display Characters – Height: 0.433" (11.00mm), 0.256" (6.50mm)
9. Voltage – Supply: 100 ~ 240VAC
10. Panel Cutout Dimensions: Square - 45.00mm x 45.00mm
11. Mounting Type: Panel Mount
12. Termination Style: Screw Terminal
13. Ingress Protection: IP66 (Face), IP20 (Case), IP00 (Terminal)
14. Operating Temperature: -10°C ~ 55°C

RELATED DOCUMENTS:

1. Datasheet.

PACKAGE INCLUDES:

1. 1 X OMRON Digital Temperature Controller E5CZ-R2MT AC100-240

Note:Manufacturer Standard Lead Time Approx 6 week.
