NVIDIA Jetson TK1 Development Board

The NVIDIA Jetson TK1 developer Board gives you everything you need to unlock the power of the GPU for embedded systems applications.It's built around the revolutionary NVIDIA Tegra K1 SoC and uses the same NVIDIA Kepler computing core designed into supercomputers around the world. This gives you a fully functional NVIDIA CUDA platform for quickly developing and deploying compute-intensive systems for computer vision, robotics, medicine, and more.

NVIDIA delivers the entire BSP and software stack, including CUDA, OpenGL 4.4, and Tegra-accelerated OpenCV. With a complete suite of development and profiling tools, plus out-of-the-box support for cameras and other peripherals, NVIDIA gives you the ideal solution for helping shape the future of embedded on our Jetson Embedded Portal.

SPECIFICATIONS:

1. NVIDIA Kepler GPU with 192 CUDA Cores
2. NVIDIA 4-Plus-1™ Quad-Core ARM® Cortex™-A15 CPU
3. 2 GB x16 Memory with 64-bit Width
4. 16 GB 4.51 eMMC Memory
5. 1 Half Mini-PCIE Slot
6. 1 Full-Size SD/MMC Connector
7. 1 Full-Size HDMI Port
8. 1 USB 2.0 Port, Micro AB
9. 1 USB 3.0 Port, A
10. 1 RS232 Serial Port
11. 1 ALC5639 Realtek Audio Codec with Mic
12. 1 RTL8111GS Realtek GigE LAN
13. 1 SATA Data Port
14. SPI 4 MByte Boot Flash

PIN CONFIGURATIONS:

APPLICATIONS:

 NVIDIA Jetson is the world's leading visual computing platform for GPU-accelerated parallel processing in the mobile embedded systems market. Its high-performance, low-energy computing for deep learning and computer vision makes Jetson the ideal solution for compute-intensive embedded projects like:

1. Drones
2. Autonomous Robotic Systems
3. Mobile Medical Imaging

PHYSICAL DIAGRAM:

PACKAGE INCLUDES:

1. 1 X NVIDIA Jetson TK1 Development Board
