MyActuator: High Precision Servo Actuator Module RMD-X6 V2 1:6 - A00105

Special Price PKR98,500.00 was PKR114,000.00
Quantity: 0

Technical specifications

参数/型号   RMD-X6
货品编码   A00105
减速机速比(Reducer ratio)    6 : 1
输入电压(input voltage) V 24-48
 最大空载转速 (No -load Speed) rpm 240 @24V
额定转速 (Nominal Speed) rpm 190
额定电流(Nominal current) A 4
额定功率(Norminal power) W 70
额定扭矩 (Nominal torque) N.M 3.5
电机效率(motor efficency) % 70%
线电阻(resistance) 0.33
接线方式(wire connect)   Y
相间电感(Phase to phase inductance) mH 0.19
转速常数(Speed constant) rpm/v 60
扭矩电流常数(Torque constant) N.M/A 0.88
轴向负载 (Axial direction payload) N.M 775
径向负载(Radial direction payload) N.M 1250
转子惯量(Rotor inertia) gc㎡ 800
极对数(Number of pole pairs)   14
电机重量( Motor weight) g 335
环境温度 (Environment  temperature) (-20 ~ 55 ℃)
减速箱背隙(Backlash) Arc min 5
Part Number RMD-X6 V2 1:6 || A00105
Manufacturer MY ACTUATOR
Packing Unit 1 Piece
Product Availability Available on Demand
