MikroE: EasyPIC FUSION v7 Ethernet MCUcard with PIC32MX795F512L - MIKROE-1206

SKU
MD-01998
-16%
Special Price PKR29,500.00 was PKR35,000.00
Quantity: 5

The ETHERNET MCU card. It contains PIC32MX795F512L microcontroller with on-chip peripherals and is a great choice for both beginners and professionals. After testing and building the final program, this card can also be taken out of the board socket and used in your final device.

PIC32MX795F512L has 80MHz maximum frequency, 512K bytes of program memory (flash), 128K bytes of data memory. It has integrated Ethernet controller, USB (OTG, Host, Device), 85 General purpose I/O pins, 5 16-bit timers, 16 Analog Input pins (ADC), 6 UARTs, internal 8 MHz and 32kHz oscillators, internal Real time clock (RTC), 5 I2C, 4 SPI and 2 CAN controllers. It also contains 3 analog comparators and two programming and debugging interfaces.

8MHz crystal oscillator. We carefully chose the most convenient crystal value that provides clock frequency which can be used directly, or with the PLL multipliers to create higher MCU clock value. MCU card also contains 32.768 kHz crystal oscillator which provides external clock waveform for RTCC module.

USB communications lines. These two jumpers, when in USB position, connect D+ and D- lines of the on-board USB connector with RG2 and RG3 microcontroller pins. Since PIC32MX795F512L supports USB, jumpers are in USB position.

Ethernet transceiver. This MCU card contains single-chip Ethernet physical (PHY) layer transceiver which provides additional Ethernet functionality to PIC32MX795F512L controller.

25MHz crystal oscillator. This crystal oscillator is connected to external Ethernet module.

Part Number MIKROE-1206
Manufacturer MikroElektronika
Weight (KG) 0.010000
Packing Unit 1 Piece
Product Availability In Stock
