Meanwell: AC-DC Single Output Power Supply with PFC; 48VDC 105A 5000W - RST-5000-48
SKU
MS-02086
PKR578,000.00
Quantity: 0
AC-DC Single output power supply with PFC; 3 wire 196-305 or 4 wire 340-530 VAC; Output 48VDC at 105A; Current sharing 1+3 unit; Built-in Dc fan
Category: Power Supply
Specifications
| Technical data | |
|---|---|
|
Brand
|
Mean Well
|
|
Item number
|
RST-5000-48
|
|
Series
|
RST-5000
|
|
Description
|
AC-DC Single output power supply with PFC; 3 wire 196-305 or 4 wire 340-530 VAC; Output 48VDC at 105A; Current sharing 1+3 unit; Built-in Dc fan
|
|
Application
|
ITE EN/UL/IEC 60950
|
|
Technology
|
AC/DC
|
|
Power Format
|
Box Type - Enclosed
|
|
Output Power (W)
|
5000
|
|
Output Voltage (V)
|
48
|
|
Output Current (A)
|
105
|
|
Input Voltage (V)
|
196 - 305
340 - 530
|
|
IP Rating
|
No IP assigned
|
|
Width (mm)
|
211
|
|
Height (mm)
|
83.5
|
|
Depth (mm)
|
460
|
|
Control Signals
|
Fan Fail
ON/OFF
Remote Sense
Vaux auxilary
|
|
Dimming Technology
|
No Dimming
|
| Part Number | RST-5000-48 |
|---|---|
| Manufacturer | Mean Well |
| Weight (KG) | 10.000000 |
| Packing Unit | 1 Piece |
| Custom tariff number | 8504408390 |
| Product Availability | Available on Demand |
| Voltage (V) | NA |
| Output Voltage | NA |
| Output Impedance | NA |
| Power | NA |
| Temperature Range (Max) | NA |
| Temperature Range (Min) | NA |
