Power Supply : 2×1.5V AAA Batteries
● Product Size : 238x43x29mm/9.37x1.7x1.1"
● Product Weight : 112g/0.28lb
● Certificate : CE / ETL / RoHS
● Safety Rating : CATIII 600V
Features
● Display 2000 counts
● Auto & Manual Ranging
● Auto Power Off
● Diode Open Voltage 1.5V
● Maximum Value Hold
● Data Hold
● Low Battery Display
● Continuity Buzzer <50±20Ω
● NCV Detection >50V AC
● Logic Level Test
● Double Molding
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
200mV/2V/20V/200V/600V |
0.1mV/1mV/20mV/0.1V/1V |
±(0.7%+2) |
|
AC Voltage |
200mV/2V/20V/200V 600V |
0.1mV/1mV/20mV/0.1V 1V |
±(0.8%+3) ±(1.0%+3) |
|
Resistance |
200Ω 2kΩ /20kΩ /200kΩ /2Μ Ω 20Μ Ω |
0.1Ω 1Ω /10Ω /0.1kΩ /1kΩ 0.01Μ Ω |
±(1.0%+3) ±(1.0%+1) ±(1.0%+5) |
|
DC Current |
20mA/200mA |
20μA/0.1mA |
±(1.5%+3) |
|
AC Current |
20mA/200mA |
20μA/0.1mA |
±(2.0%+3) |
| Part Number | MS8212A |
|---|---|
| Manufacturer | Mastech Group |
| Weight (KG) | 0.200000 |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
