LM35D Digital Temperature Sensor Module

Specification:

1) Dimensions: 28.2mm (length) * 13.1mm (W) * 5.5mm (height)
2) Weight: 5g
3) Operating voltage: 4V - 30V
4) Sensor Model: LM35DZ
5) Signal Output Type: Analog
6) Temperature measuring range: 0 - 100
7) Measuring accuracy: 0.5
8) linear scale factor: +10 mV
9) Low power consumption, less than 60uA
10) low output impedance, 1mA current through only 0.1
11) with screw holes for easy installation and fixed. Aperture 2.6mm
Second, the wiring instructions:
"+": Positive power supply
"-": Negative one
"out": pick AD converter module analog signal input terminal or directly connected to the multimeter to measure
