Intel RealSense Stereoscope Depth Camera 90fps - D455
SKU
MD-02281
Categories: Camera Module, Camera
The RealSense® RealSense™ Depth Camera D455 takes what makes the D435 products great and make them even better by increasing range and accuracy by a factor of two. The SDK 2.0 is designed to allow seamless transitions from one generation to the next and between our cameras.
- Longer range for collision avoidance.
- Matched RGB and Depth images make for easy scan recreations.
- Easier creation of digital twins with multiple cameras in real-time.
- Monitor patients or interact with digital sign viewers with increased precision at longer range.
- Integrates an IMU to allow your application to refine its depth awareness in any situation where the camera moves.
The latest release of the RealSense® RealSense™ SDK 2.0 is available on our GitHub page at https://github.com/IntelRealSense/librealsense/.
Specifications:
| Use Environment | Indoor/Outdoor |
| Image Sensor Technology | Global Shutter |
| Ideal Range | .6 m to 6 m |
| Depth Technology | Stereoscopic |
| Minimum Depth Distance (Min-Z) at Max Resolution | ~52 cm |
| Depth Accuracy | <2% at 4 m |
| Depth Field of View (FOV) | 87° × 58° |
| Depth Stream Output Resolution | Up to 1280 × 720 |
| Depth Stream Output Frame Rate | Up to 90 fps |
| RGB Frame Resolution | 1280 × 800 |
| RGB Frame Rate | 30 fps |
| RGB Sensor Technology | Global Shutter |
| RGB Sensor FOV | 90° × 65° |
| RGB Sensor Resolution | 1 MP |
| Camera Module | RealSense Module D450 |
| Vision Processor Board | RealSense Vision Processor D4 |
| Form factor | Camera Peripheral |
| Camera Dimension (Length × Depth × Height) |
124 mm × 26 mm × 29 mm |
| Connectors | USB-C* 3.1 Gen 1* |
| Mounting Mechanism | – One 1/4‑20 UNC thread mounting point – Two M4 thread mounting points – Tripod |
| Part Number | D455 |
|---|---|
| Manufacturer | Intel® |
| Weight (KG) | 0.300000 |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
