Industrial Control Amplifier Board 4, 8, 12, 16 Channel
SKU
MD-01676
PKR 2,870.00
🔥 High Demand Allocation:
4 Units
⚠️ Limited Quantity Remaining
Category: Relay Module
This model is the SV-5A1R8P-x . Model analysis: SV (digital signal amplifier) -5A (maximum drive current per channel 5A) -1R (one-way transmission) 4P(4 channels) - x (N is NPN output, that is, the output of the drain) (P is the PNP output) Source output).
- Adopt new original imported FET.
- The input signal is compatible with NPN and PNP, and is compatible with PLC equipment such as Mitsubishi, Panasonic, Siemens, and domestic PLC.
- The signal input voltage is 3.3V/5V/12V/24V, which is convenient for different signal generation equipment control.
- Protection measures: Each channel of the input adopts photoelectric isolation module to effectively protect the safety of the control terminal; at the same time, it is equipped with eight bipolar status indicators. The output has diode anti-surge protection, and the power supply has diode anti-reverse protection.
- Wiring: VCC and GND are the power supply ports of this module, and are wired according to the prompt voltage. COM is connected to the signal control terminal common pole, 1-8 is connected to each channel control signal; the output of the controlled device is open drain output, labeled O1-O8.
- Installation: DIN 35 mm rail installation, convenient and fast!
| Part Number | SV-5A1R8P |
|---|---|
| Manufacturer | NA / Unknown |
| Weight (KG) | 0.020000 |
| Product Availability | In Stock |
