RC Brushless Electronic Speed Controller (HLW XXD-30A)

SKU
MD-00288
PKR1,350.00
Quantity: 0
HLW XXD-30A Support brushless motor an unlimited maximum speed With careful circuit design, super strong anti-jamming. The three independent high-precision low dropout voltage regulator (LDO) for MCU.
  • Buy 3 for PKR1,190.00 each and save 12%
  • Buy 10 for PKR1,150.00 each and save 15%
  • Buy 50 for PKR1,050.00 each and save 22%

HLW XXD-30A Support brushless motor an unlimited maximum speed With careful circuit design, super strong anti-jamming. The three independent high-precision low dropout voltage regulator (LDO) for MCU.

FEATURES:

  1. Safe startup mode:When switch on power, SC won’t be started no matter throttle rocker at which positions, safe and reliable.
  2. Low volts protection: When input volts lower than setted value, ESC will reduce or shut down the output automatically, protecting battery effectively.
  3. Over volts protection: When input volts higher than rated volts,it emit warning tone,and stop working, self-protecting effectively.
  4. Over-heat protection: When the temperature is over 100 celsius degree, the ESC will reduce the output power, protecting ESC effectively.
  5. Battery type: Li-xx(Li-ion or Li-poly) / Ni-xx(NiMh or Nicd).
  6. Startup mode: normal / soft / super-soft, default is normal startup.
  7. Transmitter compatibility: Throttle is being settable, compatible with all transmitters.
  8. Security: If lost signal in normal use, the ESC would shut down output,prevent the loss caused by lost control

SPECIFICATIONS:

  1. Model: HW30A
  2. No loading current: 30A
  3. Continue current: 30A
  4. Max current: 40A (up to 10s)
  5. BEC current: Max 2Amp, linear volts regulator.
  6. Speed(Max): 2pole motor 210000 RPM 6 pole motor 70000 rpm,Pole motor 35000 Rev/min
  7. The motor feed settings: Auto/low/high, default automatic
  8. PWM operating frequency: 8kHz /16kHz, the default 16HZ
  9. The model helicopter (helicopter): off/on, default to turn off

HOW TO USE:

How to used with Motors



RELATED DOCUMENTS:

  1. HLW XXD-30A RC Brushless Electronic Speed Controller Instructions.

PACKAGE INCLUDES:

  1. 1 X RC Brushless Electronic Speed Controller (HLW XXD-30A )
Part Number NA
Weight (KG) 0.039500
Manufacturer Made in China
Voltage (Min) 4V
Voltage (Max) 16V
Output Voltage NA
Power NA
Current (A) 30
Frequency 16kHZ
Load Cell (kg) NA
Output Type DC
Range NA
Temperature Range (Min) 0°C
Temperature Range (Max) 100°C
Operating System NA
Resistance Value (Ohm) NA
Baud Rate NA
Interface NA
Num of Pin's NA
Size (mm) 32 X 24 X 7mm
