Hall Effect AC Split Core Current Transformer Module 100A, Output 4-20mAh - BSQ06CT
SKU
MD-02216
PKR4,200.00
Quantity: 3
Hall Effect AC Current Transformer Module 100A, 4-20mAh - BSQ06CT
- Buy 3 for PKR3,990.00 each and save 5%
- Buy 10 for PKR3,864.00 each and save 8%
Categories: Current Sensors, Power Module
BSQ06CT hall effect current Sensor is an open loop device based on the measuring principle of the hall effect, with a galvanic isolation between primary and secondary circuit. It provides accurate electronic measurement of AC currents.
SPECIFICATIONS:
|
Type |
BSQ06CT |
Unit |
|
Rated current(Ipn AC) |
100 |
A |
|
Measure range(Ip AC) |
0-150 |
A |
|
Rated output |
4-20mA |
V |
|
Supply voltage |
+24V |
V |
|
Power Consumption |
<25 |
mA |
HOW TO USE:
- When the current will be measured goes through a Sensor, the voltage will be measured at the output end.(Note: The false wiring may result in the damage of the Sensor).
- The output amplitude of the Sensor can be adjusted according to user's requirements.
APPLICATIONS:
- Variable speed drives
- Welding machine
- Battery supplied applications
- Uninterruptible Power Supplies (UPS)
- Electrochemical
PACKAGE INCLUDES:
- Hall Effect AC Current Transformer Module 100A, 4-20mAh - BSQ06CT
| Part Number | BSQ06CT |
|---|---|
| Manufacturer | Made in China |
| Weight (KG) | 0.020000 |
| Input Current | NA |
| Packing Unit | 1 Piece |
| Product Availability | In Stock |
