GRATTEN Dual Channel Variable DC Power Supply APS3005S-3D (O~30V/0~5A)

SKU
MD-00420
PKR62,800.00
Quantity: 4
GRATTEN Dual Channel DC Power Supply APS3005S-3D (O~30V/0~5A)
  • Buy 3 for PKR59,660.00 each and save 5%
  • Buy 10 for PKR57,776.00 each and save 8%

GRATTEN Dual Channel DC Power Supply APS3005S-3D (O~30V/0~5A)

FEATURES:

  1. O~30V,0~5A dual channel adjustable and one fixed 5V/3A
  2. Over current protection
  3. Constant voltage,constant current,low ripple noise,low temperature drift
  4. Preset current limited point
  5. In tracking mode, both outputs are automatically connected in series or parallel without extra cables
  6. In series mode, machine can be connected as positive and negative supply
  7. Multiturn potentiometers,easy to setup ,voltage’s value.
  8. High efficient toroidal transformer
  9. Dual color, four LED digital panel meters for voltage and curent
  10. The radiator built-in.

 TECHNICAL SPECIFICATIONS:

                                                                       Parameters

Display accuracy  ± 0.5% rdg + 2 words
 Ripple and noise  1mVrms
 Load  0.01% + 3mV
 Digital resolution  Voltage 0.1V Current 0.01A
 Auxiliary Supply voltage  5V
 Auxiliary power supply current  3A
 Series-parallel synchronization error  <0.5% + 10mV (2-channel )
 Series adjusted rate  <300mV
 Ripple Noise  < 2mVrms 5Hz ~ 1MHz

PHYSICAL DIAGRAM:

 PHYSICAL DIAGRAM

PACKAGE INCLUDES:

  1. 1 x GRATTEN Dual Channel DC Power Supply APS3005S-3D (O~30V/0~5A)
  2. 1 x Power Cable
Part Number APS3005S-3D
Manufacturer ATTEN
Weight (KG) 8.000000
Packing Unit 1 Piece
Size (mm) 15.75in x 11.81in x 7.87in
Product Availability Available on Demand
Voltage (V) AC 220 ± 10% 50Hz
Output Voltage 0~30V Adjustable Voltage (Dual)
Output Impedance NA
Power NA
Current (A) 0~5 Power Supply Adjustable (Dual)
Temperature Range (Max) 70°C
Temperature Range (Min) -10°C
