RF Encoder Decoder IC HT12D (DIP-18)

HT12E and HT12D are Encoder Decoder ICs manufactured by Holtek for Remote Control Applications. These ICs can be used with ASK RF Transmitter and Receiver modules. By using the paired HT12E encoder and HT12D decoder we can transmit 12 bits of parallel data serially. HT12D simply converts serial data to its input (may be received through RF receiver) to 12 bit parallel data. These 12 bit parallel data is divided in to 8 address bits and 4 data bits. Using 8 address bits we can provide 8 bit security code for 4 bit data and can be used to address multiple receivers by using the same transmitter.

FEATURES:

1. Wide Operating Voltage Range, 2.4V – 12V
2. Low Power Consumption
3. High Noise Immunity
4. Low Standby Current
5. 8 Bit Address and 4 Bit Data
6. Minimal External Components
7. On-Chip Oscillator, needs only 5% resistor

RELATED DOCUMENTS:

1. HT12E Datasheet.
2. HT12D Datasheet.

APPLICATIONS:

1. Remote Control Systems
2. Burglar Alarms
3. Cordless Telephones
4. Smoke & Fire Alarm Systems
5. Security Systems
6. Garage and Car Door Controllers
7. Car Alarm Systems

PACKAGE INCLUDES:

1. 1 X Encoder Decoder Pair IC HT12E/HT12D (DIP-18)
