Electronic Weight Sensor L1E-Load Cell
SKU
MD-00306
As low as
PKR5,000.00
Quantity: 0
This Electronic Weight Sensor can translate up to 50-300kg of pressure (force) into an electrical signal.
This Electronic Weight Sensor can translate up to 50-300kg of pressure (force) into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to, and proportional of, the strain (e.g. pressure or force) applied to the bar. With this gauge you will be able to tell just how heavy an object is, if an object’s weight changes over time, or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.
SPECIFICATIONS:
| Product Name | Electronic Weight Sensor-Load Cell |
| Rated Load | 50Kg /60Kg /80Kg /100Kg /150Kg /200Kg /250Kg /300Kg |
| Rated Output | 2.0±0.2mV/V |
| Input impedance | 406 ± 6Ohm |
| Output Impedance | 350 ± 3Ohm |
| Insulation resistance | ≥5000 (50VDC) MOhm |
| Compensated Temperature Range | -10 °C~+40°C |
| Safety Overload | 120%F.S |
| Recommend Excitation Voltage | 5 ~ 12 (DC) |
| Max Excitation Voltage | DC 18V |
| Cable Length | 2m |
| Material | Aluminium Alloy |
| Ultimate overload range | 150%F.S |
| Recommended weighing platform size | 30 * 40mm or 400x500mm |
| Eccentricity deviation | 0.02% load value / 100mm |
| Recommended mounting torque | 20Nm |
APPLICATIONS:
- Strain measurement
- Digital and Analog Electronic Weighing scales
- Weight Balancing Machines
PACKAGE INCLUDES:
- 1 X Electronic Weight Sensor L1E-Load Cell
| Manufacturer | Made in China |
|---|---|
| Voltage (Min) | 5V |
| Voltage (Max) | 12V |
| Output Voltage | NA |
| Power | NA |
| Current (A) | NA |
| Frequency | NA |
| Output Type | Voltage Signal |
| Range | 50Kg /60Kg /80Kg /100Kg /150Kg /200Kg /250Kg /300Kg |
| Temperature Range (Min) | -25°C |
| Temperature Range (Max) | 65°C |
| Num of Pin's | 4 |
| Size (mm) | 15cm X 3.5cm X 4cm |
