EK FC-Titan X Nickel Water Blocker

EK-FC Titan X is a high performance full-cover water block for nVidia reference (NVA-PG600) design GeForce GTX Titan X and GTX 980 Ti series graphics cards. This water block directly cools the GPU, RAM as well as VRM (voltage regulation module) as water flows directly over these critical areas thus allowing the graphics card and it's VRM to remain stable under high overclocks. EK-FC Titan X water block features a central inlet split-flow cooling engine design for best possible cooling performance, which also works flawlessly with reversed water flow without adversely affecting the cooling performance. Moreover, such design offers great hydraulic perfromance allowing this product to be used in liquid cooling systems using weaker water pumps.Base is made of nickel-plated electrolytic copper while the top is made of quality acrylic material. The top also features two pre-drilled slots for 3mm LED diodes. The sealing is ensured by quality rubber washers. Screw-in brass standoffs are pre-installed and allow for safe, painless installation procedure. Block is mounted with enclosed M3 DIN7985 screws.

 EKWB recommends aesthetic retention backplate (EK-FC Titan X Backplate - Black, Nickel, Blue, Red, Gold) which improves the looks of your graphics cards and also provide some passive cooling to the circuit board VRM section.G1/4" threaded fittings can be used on both sides of the FC terminal. Up to four EK-FC Titan X water blocks can be used on a single ATX form factor motherboard by using EK-FC Terminal (DUAL, TRIPLE or QUAD type) system or other means of interconnectivity. Please note that EK-FC Bridge & Link system is not compatible with this water block.

HOW TO CONNECT:

RELATED DOCUMENTS:

1. EK FC-Titan X Nickel Water Blocker Installation Guide.

PACKAGE INCLUDES:

1. 1 X EK FC-Titan X Nickel Water Blocker
