Dust Sensor Detector Module with GP2Y1010AU0F

-Sharp GP2Y1010AU0F onboard, detecting fine particle larger than 0.8m in diameter, even like the cigarette smoke
-Low power consumption, analog voltage output, the output level is linear with dust density
-Embedded voltage boost circuit to support wide range of power supply

Specifications:

1) Sensitivity : 0.5V/(100g/m3)
2) Measurement range : 500g/m3
3) Power : 2.5V~5.5V
4) Operating current : 20mA(max)
5) Operating temperature : -10~65 Centigrade
6) Storage temperature : -20~80 Centigrade
7) Life time : 5 years
8) Dimension : 63.2mm×41.3mm×21.1mm
9) Mounting holes size : 2.0mm
10) Air hole size : 9.0mm

Applications:

1) Air purifier
2) Air conditioner
3) Air monitor
4) PM2.5 Detector

How to Use:

In the case of working with a MCU:

1) VCC 2.5V ~ 5.0V
2) GPD GND
3) AOUT MCU.IO (analog output)
4) ILED MCU.IO (module driving pin)
