Dowsil: 3145 RTV Silicone Adhesive Sealant Gray/Clear 305 mL Cartridge - MIL-A-46146
SKU
MD-01969
Category: Consumer Electronics
Dow DOWSIL™ 3145 RTV MIL-A-46146 Adhesive Sealant Gray is a one component, room temperature curing, silicone adhesive that is used for assembling print wire boards, yokes, adding mechanical stability, and sealing housings, modules, and electrical leads. It is non-flowing, adds thermal stability, high temperature stability, and has high elongation and tensile strength. 305 mL Cartridge.
Product Details
| Typical Use: | Sealing openings in modules and housings; adding mechanical stability to individual components; assembly of components on PWBs; sealing in and around wires and electrical leads; yoke assembly. |
| Brand: | DOWSIL |
| Color: | Gray / Clear |
| Components: | 1 part |
| Cure System: | RTV |
| Cure Time: | 48h @ room temperature |
| Dielectric Strength: | 500 V/mil |
| Elongation: | 670% |
| Hardness: | 51 A |
| Key Specifications: | MIL-A-46146 Rev. B, Amend. 3 Group III, CERT |
| Service Temperature: | 50 to 200 °C |
| Shear Strength: | 1,900 |
| Specific Gravity: | 1.12 @ 25 °C |
| Tack Free Time: | 78min |
| Tensile Strength: | 1,035 psi |
| Viscosity: | Non-flow |
| Part Number | 3145-RTV-310ML - MIL-A-46146 |
|---|---|
| Manufacturer | Dow Corporation |
| Weight (KG) | 300.000000 |
| Packing Unit | 1 Piece |
| Product Availability | Available on Demand |
