DFRobot: Gravity: Analog Capacitive Soil Moisture Sensor- Corrosion Resistant - SEN0193

This product measures soil moisture levels by capacitive sensing, rather than resistive sensing like other types of moisture sensor. It is made of a corrosion-resistant material giving it long service life. Insert it into the soil and impress your friends with the real-time soil moisture data!

The product includes an on-board voltage regulator which gives it an operating voltage range of 3.3 ~ 5.5V. It is compatible with low-voltage MCUs (both 3.3V and 5V logic). To make it compatible with a Raspberry Pi, an ADC converter is required.

The following image shows an example project - a device that notifies you when a plant needs to be watered.



Hardware Components:

• Particle Photon
• Soil Moisture Sensor For Arduino
• I2C 16x2 Arduino LCD Display Module
• RGB Diffused Common Cathode
• Micro USB Connector
• Uxcell Perf Board 4x6cm

Particle Photon Project 2: Annoying Soil Moisture Sensor with Photon and IFTTT Project

Never forget to water your plants again with this super annoying project. It combines visual, auditory, and textual cues that will prevent you from doing anything else until you provide your plant with much-needed hydration. A piezo buzzer constantly blares a shrill note, while a super-bright LED annoys your peripheral vision. In addition, this project will send constant texts to your phone reminding you that your plant needs to be watered. Sounds like fun, right?

•

• Supports Gravity 3-Pin Interface
• Analog Output

• Gardening & Farming
• Moisture Detection
• Intelligent Agriculture

• Operating Voltage: 3.3 ~ 5.5 VDC
• Output Voltage: 1.2 ~ 2.5V
• Interface: PH2.0-3P
• Dimension: 98mm * 23mm (3.86in x 0.905in)
• Weight: 15g

• Capacitive Soil Moisture Sensor x1
• Analog Sensor Cable x1
