DFRobot 3PA Robot Car Kit For Arduino

The DFRobot 2WD robot is widely used as a development platform for the Arduino microcontroller. Arduino has world's largest number of users when it comes to hobby microcontrollers and there is a lot of code and project examples available.  The differential drive allows for a near zero turning radius while the high-strength aluminum alloy body plus high-quality high-speed motors make it suitable for flat indoor surfaces and flat-platform robot completitions.

The top layer includes a standard servo socket and the three optional sensor holder. This three sensor holder fits with our adjustable IR range sensor. The servo can be used for a simple rotation platform, a two degrees of freedom camera holder or even a robotic arm.

FEATURES:

1. Two differential drive
2. Caster ball included
3. Complete chassis with mounting hardware
4. Motor type: 130
5. Motor Voltage: 4.5-6V
6. Motor: 10,000 rpm
7. Reduction ratio: 1: 120
8. Maximum speed: 48cm/s
9. Motor no-load current: 400mA
10. Motor Stall Current: about 800mA
11. Wheel diameter: 65mm

Assembly:

1. Connect each motor to the vertical supports using the included screws and nuts
2. Wire the motors
3. Mount the ball caster in the lower frame
4. Screw the on/off switch and power plug into the top frame
5. Wire the on/off switch and power to your motor controller
6. Srew the top frames to the lower frame
7. Connect the wheels to the motors
8. The additional metal parts are used at your discretion but are not necessary.

RELATED DOCUMENTS:

1. DFRobot 3PA Robot Car Kit For Arduino Datasheet.
2. DFRobot 3PA Robot Car Kit For Arduino Assembly Instructions.


PACKAGE INCLUDES:

1. 1 X DFRobot 3PA Robot Car Kit For Arduino
